python机器学习理论与实战（六）支持向量机

def smoPK(dataMatIn, classLabels, C, toler, maxIter): #full Platt SMO  oS = optStruct(mat(dataMatIn),mat(classLabels).transpose(),C,toler)  iter = 0  entireSet = True; alphaPairsChanged = 0  while (iter < maxIter) and ((alphaPairsChanged > 0) or (entireSet)):   alphaPairsChanged = 0   if entireSet: #go over all    for i in range(oS.m):       alphaPairsChanged += innerL(i,oS)     print "fullSet, iter: %d i:%d, pairs changed %d" % (iter,i,alphaPairsChanged)    iter += 1   else:#go over non-bound (railed) alphas    nonBoundIs = nonzero((oS.alphas.A > 0) * (oS.alphas.A < C))[0]    for i in nonBoundIs:     alphaPairsChanged += innerL(i,oS)     print "non-bound, iter: %d i:%d, pairs changed %d" % (iter,i,alphaPairsChanged)    iter += 1   if entireSet: entireSet = False #toggle entire set loop   elif (alphaPairsChanged == 0): entireSet = True   print "iteration number: %d" % iter  return oS.b,oS.alphas

from numpy import * from time import sleep  def loadDataSet(fileName):  dataMat = []; labelMat = []  fr = open(fileName)  for line in fr.readlines():   lineArr = line.strip().split('/t')   dataMat.append([float(lineArr[0]), float(lineArr[1])])   labelMat.append(float(lineArr[2]))  return dataMat,labelMat  def selectJrand(i,m):  j=i #we want to select any J not equal to i  while (j==i):   j = int(random.uniform(0,m))  return j  def clipAlpha(aj,H,L):  if aj > H:   aj = H  if L > aj:   aj = L  return aj  def smoSimple(dataMatIn, classLabels, C, toler, maxIter):  dataMatrix = mat(dataMatIn); labelMat = mat(classLabels).transpose()  b = 0; m,n = shape(dataMatrix)  alphas = mat(zeros((m,1)))  iter = 0  while (iter < maxIter):   alphaPairsChanged = 0   for i in range(m):    fXi = float(multiply(alphas,labelMat).T*(dataMatrix*dataMatrix[i,:].T)) + b    Ei = fXi - float(labelMat[i])#if checks if an example violates KKT conditions    if ((labelMat[i]*Ei < -toler) and (alphas[i] < C)) or ((labelMat[i]*Ei > toler) and (alphas[i] > 0)):     j = selectJrand(i,m)     fXj = float(multiply(alphas,labelMat).T*(dataMatrix*dataMatrix[j,:].T)) + b     Ej = fXj - float(labelMat[j])     alphaIold = alphas[i].copy(); alphaJold = alphas[j].copy();     if (labelMat[i] != labelMat[j]):      L = max(0, alphas[j] - alphas[i])      H = min(C, C + alphas[j] - alphas[i])     else:      L = max(0, alphas[j] + alphas[i] - C)      H = min(C, alphas[j] + alphas[i])     if L==H: print "L==H"; continue     eta = 2.0 * dataMatrix[i,:]*dataMatrix[j,:].T - dataMatrix[i,:]*dataMatrix[i,:].T - dataMatrix[j,:]*dataMatrix[j,:].T     if eta >= 0: print "eta>=0"; continue     alphas[j] -= labelMat[j]*(Ei - Ej)/eta     alphas[j] = clipAlpha(alphas[j],H,L)     if (abs(alphas[j] - alphaJold) < 0.00001): print "j not moving enough"; continue     alphas[i] += labelMat[j]*labelMat[i]*(alphaJold - alphas[j])#update i by the same amount as j                   #the update is in the oppostie direction     b1 = b - Ei- labelMat[i]*(alphas[i]-alphaIold)*dataMatrix[i,:]*dataMatrix[i,:].T - labelMat[j]*(alphas[j]-alphaJold)*dataMatrix[i,:]*dataMatrix[j,:].T     b2 = b - Ej- labelMat[i]*(alphas[i]-alphaIold)*dataMatrix[i,:]*dataMatrix[j,:].T - labelMat[j]*(alphas[j]-alphaJold)*dataMatrix[j,:]*dataMatrix[j,:].T     if (0 < alphas[i]) and (C > alphas[i]): b = b1     elif (0 < alphas[j]) and (C > alphas[j]): b = b2     else: b = (b1 + b2)/2.0     alphaPairsChanged += 1     print "iter: %d i:%d, pairs changed %d" % (iter,i,alphaPairsChanged)   if (alphaPairsChanged == 0): iter += 1   else: iter = 0   print "iteration number: %d" % iter  return b,alphas  def kernelTrans(X, A, kTup): #calc the kernel or transform data to a higher dimensional space  m,n = shape(X)  K = mat(zeros((m,1)))  if kTup[0]=='lin': K = X * A.T #linear kernel  elif kTup[0]=='rbf':   for j in range(m):    deltaRow = X[j,:] - A    K[j] = deltaRow*deltaRow.T   K = exp(K/(-1*kTup[1]**2)) #divide in NumPy is element-wise not matrix like Matlab  else: raise NameError('Houston We Have a Problem -- /  That Kernel is not recognized')  return K  class optStruct:  def __init__(self,dataMatIn, classLabels, C, toler, kTup): # Initialize the structure with the parameters   self.X = dataMatIn   self.labelMat = classLabels   self.C = C   self.tol = toler   self.m = shape(dataMatIn)[0]   self.alphas = mat(zeros((self.m,1)))   self.b = 0   self.eCache = mat(zeros((self.m,2))) #first column is valid flag   self.K = mat(zeros((self.m,self.m)))   for i in range(self.m):    self.K[:,i] = kernelTrans(self.X, self.X[i,:], kTup)    def calcEk(oS, k):  fXk = float(multiply(oS.alphas,oS.labelMat).T*oS.K[:,k] + oS.b)  Ek = fXk - float(oS.labelMat[k])  return Ek    def selectJ(i, oS, Ei):   #this is the second choice -heurstic, and calcs Ej  maxK = -1; maxDeltaE = 0; Ej = 0  oS.eCache[i] = [1,Ei] #set valid #choose the alpha that gives the maximum delta E  validEcacheList = nonzero(oS.eCache[:,0].A)[0]  if (len(validEcacheList)) > 1:   for k in validEcacheList: #loop through valid Ecache values and find the one that maximizes delta E    if k == i: continue #don't calc for i, waste of time    Ek = calcEk(oS, k)    deltaE = abs(Ei - Ek)    if (deltaE > maxDeltaE):     maxK = k; maxDeltaE = deltaE; Ej = Ek   return maxK, Ej  else: #in this case (first time around) we don't have any valid eCache values   j = selectJrand(i, oS.m)   Ej = calcEk(oS, j)  return j, Ej  def updateEk(oS, k):#after any alpha has changed update the new value in the cache  Ek = calcEk(oS, k)  oS.eCache[k] = [1,Ek]    def innerL(i, oS):  Ei = calcEk(oS, i)  if ((oS.labelMat[i]*Ei < -oS.tol) and (oS.alphas[i] < oS.C)) or ((oS.labelMat[i]*Ei > oS.tol) and (oS.alphas[i] > 0)):   j,Ej = selectJ(i, oS, Ei) #this has been changed from selectJrand   alphaIold = oS.alphas[i].copy(); alphaJold = oS.alphas[j].copy();   if (oS.labelMat[i] != oS.labelMat[j]):    L = max(0, oS.alphas[j] - oS.alphas[i])    H = min(oS.C, oS.C + oS.alphas[j] - oS.alphas[i])   else:    L = max(0, oS.alphas[j] + oS.alphas[i] - oS.C)    H = min(oS.C, oS.alphas[j] + oS.alphas[i])   if L==H: print "L==H"; return 0   eta = 2.0 * oS.K[i,j] - oS.K[i,i] - oS.K[j,j] #changed for kernel   if eta >= 0: print "eta>=0"; return 0   oS.alphas[j] -= oS.labelMat[j]*(Ei - Ej)/eta   oS.alphas[j] = clipAlpha(oS.alphas[j],H,L)   updateEk(oS, j) #added this for the Ecache   if (abs(oS.alphas[j] - alphaJold) < 0.00001): print "j not moving enough"; return 0   oS.alphas[i] += oS.labelMat[j]*oS.labelMat[i]*(alphaJold - oS.alphas[j])#update i by the same amount as j   updateEk(oS, i) #added this for the Ecache     #the update is in the oppostie direction   b1 = oS.b - Ei- oS.labelMat[i]*(oS.alphas[i]-alphaIold)*oS.K[i,i] - oS.labelMat[j]*(oS.alphas[j]-alphaJold)*oS.K[i,j]   b2 = oS.b - Ej- oS.labelMat[i]*(oS.alphas[i]-alphaIold)*oS.K[i,j]- oS.labelMat[j]*(oS.alphas[j]-alphaJold)*oS.K[j,j]   if (0 < oS.alphas[i]) and (oS.C > oS.alphas[i]): oS.b = b1   elif (0 < oS.alphas[j]) and (oS.C > oS.alphas[j]): oS.b = b2   else: oS.b = (b1 + b2)/2.0   return 1  else: return 0  def smoP(dataMatIn, classLabels, C, toler, maxIter,kTup=('lin', 0)): #full Platt SMO  oS = optStruct(mat(dataMatIn),mat(classLabels).transpose(),C,toler, kTup)  iter = 0  entireSet = True; alphaPairsChanged = 0  while (iter < maxIter) and ((alphaPairsChanged > 0) or (entireSet)):   alphaPairsChanged = 0   if entireSet: #go over all    for i in range(oS.m):       alphaPairsChanged += innerL(i,oS)     print "fullSet, iter: %d i:%d, pairs changed %d" % (iter,i,alphaPairsChanged)    iter += 1   else:#go over non-bound (railed) alphas    nonBoundIs = nonzero((oS.alphas.A > 0) * (oS.alphas.A < C))[0]    for i in nonBoundIs:     alphaPairsChanged += innerL(i,oS)     print "non-bound, iter: %d i:%d, pairs changed %d" % (iter,i,alphaPairsChanged)    iter += 1   if entireSet: entireSet = False #toggle entire set loop   elif (alphaPairsChanged == 0): entireSet = True   print "iteration number: %d" % iter  return oS.b,oS.alphas  def calcWs(alphas,dataArr,classLabels):  X = mat(dataArr); labelMat = mat(classLabels).transpose()  m,n = shape(X)  w = zeros((n,1))  for i in range(m):   w += multiply(alphas[i]*labelMat[i],X[i,:].T)  return w  def testRbf(k1=1.3):  dataArr,labelArr = loadDataSet('testSetRBF.txt')  b,alphas = smoP(dataArr, labelArr, 200, 0.0001, 10000, ('rbf', k1)) #C=200 important  datMat=mat(dataArr); labelMat = mat(labelArr).transpose()  svInd=nonzero(alphas.A>0)[0]  sVs=datMat[svInd] #get matrix of only support vectors  labelSV = labelMat[svInd];  print "there are %d Support Vectors" % shape(sVs)[0]  m,n = shape(datMat)  errorCount = 0  for i in range(m):   kernelEval = kernelTrans(sVs,datMat[i,:],('rbf', k1))   predict=kernelEval.T * multiply(labelSV,alphas[svInd]) + b   if sign(predict)!=sign(labelArr[i]): errorCount += 1  print "the training error rate is: %f" % (float(errorCount)/m)  dataArr,labelArr = loadDataSet('testSetRBF2.txt')  errorCount = 0  datMat=mat(dataArr); labelMat = mat(labelArr).transpose()  m,n = shape(datMat)  for i in range(m):   kernelEval = kernelTrans(sVs,datMat[i,:],('rbf', k1))   predict=kernelEval.T * multiply(labelSV,alphas[svInd]) + b   if sign(predict)!=sign(labelArr[i]): errorCount += 1   print "the test error rate is: %f" % (float(errorCount)/m)    def img2vector(filename):  returnVect = zeros((1,1024))  fr = open(filename)  for i in range(32):   lineStr = fr.readline()   for j in range(32):    returnVect[0,32*i+j] = int(lineStr[j])  return returnVect  def loadImages(dirName):  from os import listdir  hwLabels = []  trainingFileList = listdir(dirName)   #load the training set  m = len(trainingFileList)  trainingMat = zeros((m,1024))  for i in range(m):   fileNameStr = trainingFileList[i]   fileStr = fileNameStr.split('.')[0]  #take off .txt   classNumStr = int(fileStr.split('_')[0])   if classNumStr == 9: hwLabels.append(-1)   else: hwLabels.append(1)   trainingMat[i,:] = img2vector('%s/%s' % (dirName, fileNameStr))  return trainingMat, hwLabels   def testDigits(kTup=('rbf', 10)):  dataArr,labelArr = loadImages('trainingDigits')  b,alphas = smoP(dataArr, labelArr, 200, 0.0001, 10000, kTup)  datMat=mat(dataArr); labelMat = mat(labelArr).transpose()  svInd=nonzero(alphas.A>0)[0]  sVs=datMat[svInd]  labelSV = labelMat[svInd];  print "there are %d Support Vectors" % shape(sVs)[0]  m,n = shape(datMat)  errorCount = 0  for i in range(m):   kernelEval = kernelTrans(sVs,datMat[i,:],kTup)   predict=kernelEval.T * multiply(labelSV,alphas[svInd]) + b   if sign(predict)!=sign(labelArr[i]): errorCount += 1  print "the training error rate is: %f" % (float(errorCount)/m)  dataArr,labelArr = loadImages('testDigits')  errorCount = 0  datMat=mat(dataArr); labelMat = mat(labelArr).transpose()  m,n = shape(datMat)  for i in range(m):   kernelEval = kernelTrans(sVs,datMat[i,:],kTup)   predict=kernelEval.T * multiply(labelSV,alphas[svInd]) + b   if sign(predict)!=sign(labelArr[i]): errorCount += 1   print "the test error rate is: %f" % (float(errorCount)/m)   '''''#######******************************** Non-Kernel VErsions below '''#######********************************  class optStructK:  def __init__(self,dataMatIn, classLabels, C, toler): # Initialize the structure with the parameters   self.X = dataMatIn   self.labelMat = classLabels   self.C = C   self.tol = toler   self.m = shape(dataMatIn)[0]   self.alphas = mat(zeros((self.m,1)))   self.b = 0   self.eCache = mat(zeros((self.m,2))) #first column is valid flag    def calcEkK(oS, k):  fXk = float(multiply(oS.alphas,oS.labelMat).T*(oS.X*oS.X[k,:].T)) + oS.b  Ek = fXk - float(oS.labelMat[k])  return Ek    def selectJK(i, oS, Ei):   #this is the second choice -heurstic, and calcs Ej  maxK = -1; maxDeltaE = 0; Ej = 0  oS.eCache[i] = [1,Ei] #set valid #choose the alpha that gives the maximum delta E  validEcacheList = nonzero(oS.eCache[:,0].A)[0]  if (len(validEcacheList)) > 1:   for k in validEcacheList: #loop through valid Ecache values and find the one that maximizes delta E    if k == i: continue #don't calc for i, waste of time    Ek = calcEk(oS, k)    deltaE = abs(Ei - Ek)    if (deltaE > maxDeltaE):     maxK = k; maxDeltaE = deltaE; Ej = Ek   return maxK, Ej  else: #in this case (first time around) we don't have any valid eCache values   j = selectJrand(i, oS.m)   Ej = calcEk(oS, j)  return j, Ej  def updateEkK(oS, k):#after any alpha has changed update the new value in the cache  Ek = calcEk(oS, k)  oS.eCache[k] = [1,Ek]    def innerLK(i, oS):  Ei = calcEk(oS, i)  if ((oS.labelMat[i]*Ei < -oS.tol) and (oS.alphas[i] < oS.C)) or ((oS.labelMat[i]*Ei > oS.tol) and (oS.alphas[i] > 0)):   j,Ej = selectJ(i, oS, Ei) #this has been changed from selectJrand   alphaIold = oS.alphas[i].copy(); alphaJold = oS.alphas[j].copy();   if (oS.labelMat[i] != oS.labelMat[j]):    L = max(0, oS.alphas[j] - oS.alphas[i])    H = min(oS.C, oS.C + oS.alphas[j] - oS.alphas[i])   else:    L = max(0, oS.alphas[j] + oS.alphas[i] - oS.C)    H = min(oS.C, oS.alphas[j] + oS.alphas[i])   if L==H: print "L==H"; return 0   eta = 2.0 * oS.X[i,:]*oS.X[j,:].T - oS.X[i,:]*oS.X[i,:].T - oS.X[j,:]*oS.X[j,:].T   if eta >= 0: print "eta>=0"; return 0   oS.alphas[j] -= oS.labelMat[j]*(Ei - Ej)/eta   oS.alphas[j] = clipAlpha(oS.alphas[j],H,L)   updateEk(oS, j) #added this for the Ecache   if (abs(oS.alphas[j] - alphaJold) < 0.00001): print "j not moving enough"; return 0   oS.alphas[i] += oS.labelMat[j]*oS.labelMat[i]*(alphaJold - oS.alphas[j])#update i by the same amount as j   updateEk(oS, i) #added this for the Ecache     #the update is in the oppostie direction   b1 = oS.b - Ei- oS.labelMat[i]*(oS.alphas[i]-alphaIold)*oS.X[i,:]*oS.X[i,:].T - oS.labelMat[j]*(oS.alphas[j]-alphaJold)*oS.X[i,:]*oS.X[j,:].T   b2 = oS.b - Ej- oS.labelMat[i]*(oS.alphas[i]-alphaIold)*oS.X[i,:]*oS.X[j,:].T - oS.labelMat[j]*(oS.alphas[j]-alphaJold)*oS.X[j,:]*oS.X[j,:].T   if (0 < oS.alphas[i]) and (oS.C > oS.alphas[i]): oS.b = b1   elif (0 < oS.alphas[j]) and (oS.C > oS.alphas[j]): oS.b = b2   else: oS.b = (b1 + b2)/2.0   return 1  else: return 0  def smoPK(dataMatIn, classLabels, C, toler, maxIter): #full Platt SMO  oS = optStruct(mat(dataMatIn),mat(classLabels).transpose(),C,toler)  iter = 0  entireSet = True; alphaPairsChanged = 0  while (iter < maxIter) and ((alphaPairsChanged > 0) or (entireSet)):   alphaPairsChanged = 0   if entireSet: #go over all    for i in range(oS.m):       alphaPairsChanged += innerL(i,oS)     print "fullSet, iter: %d i:%d, pairs changed %d" % (iter,i,alphaPairsChanged)    iter += 1   else:#go over non-bound (railed) alphas    nonBoundIs = nonzero((oS.alphas.A > 0) * (oS.alphas.A < C))[0]    for i in nonBoundIs:     alphaPairsChanged += innerL(i,oS)     print "non-bound, iter: %d i:%d, pairs changed %d" % (iter,i,alphaPairsChanged)    iter += 1   if entireSet: entireSet = False #toggle entire set loop   elif (alphaPairsChanged == 0): entireSet = True   print "iteration number: %d" % iter  return oS.b,oS.alphas
